| Procesador |
AMD Socket AM4, support for: |
|
- AMD Ryzen™ 5000 G-Series Processors |
|
- AMD Ryzen™ 5000 Series Processors |
|
- AMD Ryzen™ 4000 G-Series Processors |
|
- AMD Ryzen™ 3000 Series Processors |
| Chipset |
AMD A520 |
| Memoria |
2 x DDR4 DIMM sockets supporting up to 64 GB |
|
Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules |
|
Dual channel memory architecture |
|
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
|
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
|
Support for Extreme Memory Profile (XMP) memory modules |
| Gráfica Integrada |
Integrated Graphics Processor: |
|
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
|
- Support for HDMI 2.1 version, HDCP 2.3, and HDR |
|
Maximum shared memory of 16 GB |
| Audio |
Realtek® Audio CODEC |
|
High Definition Audio |
|
2/4/5.1/7.1-channel |
| LAN |
Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
| Zócalos de Expansión |
CPU: |
|
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 |
|
Chipset: |
|
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Interfaz de almacenamiento |
CPU: |
|
- 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support) |
|
Chipset: |
|
- 4 x SATA 6Gb/s connectors |
|
- Support for RAID 0, RAID 1, and RAID 10 |
| USB |
CPU: |
|
- 4 x USB 3.2 Gen 1 ports on the back panel |
|
Chipset: |
|
- 2 x USB 3.2 Gen 1 ports available through the internal USB header |
|
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
| Conectores Internos E/S |
1 x 24-pin ATX main power connector |
|
1 x 8-pin ATX 12V power connector |
|
1 x CPU fan header |
|
1 x system fan header |
|
1 x M.2 Socket 3 connector |
|
4 x SATA 6Gb/s connectors |
|
1 x front panel header |
|
1 x front panel audio header |
|
1 x USB 3.2 Gen 1 header |
|
2 x USB 2.0/1.1 headers |
|
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) |
|
1 x speaker header |
|
1 x Clear CMOS jumper |
|
1 x chassis intrusion header |
| Panel E/S Trasero |
1 x PS/2 port |
|
1 x HDMI port |
|
4 x USB 3.2 Gen 1 ports |
|
2 x USB 2.0/1.1 ports |
|
1 x RJ-45 port |
|
3 x audio jacks |
| Controlador E/S |
iTE® I/O Controller Chip |
| Monitorización Hardware |
Voltage detection |
|
Temperature detection |
|
Fan speed detection |
|
Fan fail warning |
|
Fan speed control |
| BIOS |
1 x 128 Mbit flash |
|
Use of licensed AMI UEFI BIOS |
|
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Otras Características |
Support for APP Center |
|
Bundled Software: |
|
- Norton® Internet Security (OEM version) |
|
- LAN bandwidth management software |
| Sistema Operativo |
Support for Windows 11 64-bit |
|
Support for Windows 10 64-bit |
| Formato |
Micro ATX Form Factor; 23.3cm x 19.8cm |
| Observaciones |
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. |
|
Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website. |
