ESPECIFICACIONES técnicas
| Cellular Standards | Cat 4 150/50 Mbps DL/UL |
|---|---|
| Cellular Bands | EU: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) TDD-LTE: B38/B40 (2600/2300 MHz) HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz) |
| SIM | 1× Nano SIM Card Slot |
| Wi-Fi Class | AC1200 |
|---|---|
| Wi-Fi (2.4 GHz) | 300 Mbps |
| Wi-Fi (5 GHz) | 867 Mbps |
| Wireless Standards | IEEE 802.11ac/a/b/g/n |
| Max Channel Width | 80 MHz |
| Reception Sensitivity | 11g 6 Mbps: -95 dBm 11g 54 Mbps: -77 dBm 11n HT20 MCS7: -74 dBm 11n HT40 MCS7: -71 dBm 11a 6 Mbps: -92 dBm 11a 54 Mbps: -75 dBm 11ac VHT20 MCS8: -70 dBm 11ac VHT40 MCS9: -65 dBm 11ac VHT80 MCS9: -61 dBm |
| MAX Capacity | 64 |
| Recommended Clients Limit | 32 |
| Wireless Security | WPA-PSK / WPA2-PSK |
| Wireless Functions | Smart connect WPS Wireless Schedule Wireless Clients Statistics |
| Operation Modes | 3G/4G Router Wireless Router |
|---|---|
| Cellular Mode | 4G Preferred 4G Only 3G Only |
| Cellular APN | Data Roaming Network Search Profile Create APN Settings ISP File Upgrade PIN Management |
| WAN Mode | Dynamic IP Static IP PPPoE PPTP L2TP |
| DHCP | Server DHCP Client List Address Reservation |
| NAT Forwarding | ALG Virtual Server Port Triggering UPnP DMZ |
| Protocols | IPv4 IPv6 |
| Data Settings | Data Statistics Data Limit |
| Guest Network | 2.4 GHz Guest Network 5 GHz Guest Network |
| Parental Controls | Time Control Website Filtering |
| DDNS | DynDNS NO-IP |
| SMS | Inbox New Message Outbox Drafts |
| QoS | √ |
| Security | IPv4 SPI Firewall DoS Protection Service Filtering Access Control IP & MAC Binding IPv6 Firewall |
| ISP Feature | TR-069 |
| System | Time Settings LED Control Diagnostics Firmware Upgrade Backup&Restore Reboot Administration System Log CWMP Settings SNMP Settings Traffic Monitor |
| LED Management | LED Control Night Mode |
| Device Management | MERCUSYS APP Web GUI |
| Cloud | Firmware Upgrade over the Cloud Remote Management |
| Language | English German Spanish Greek French Italian Polish Indonesian Russian Thai |
| Dimensions (W X D X H) | 219 × 140 × 32 mm (8.62 × 5.51 × 1.26 in) |
|---|---|
| Antenna | 2 External Detachable 4G LTE Antennas 2 External Wi-Fi Antennas |
| Interfaces | 1× FE LAN/WAN Port 3× FE LAN Ports 1× Nano SIM Card Slot |
| Button | 1×WPS/Wi-Fi Button 1×Reset Button |
| External Power Supply | 12V/1A |
| Installation | Desktop |
| LED | 1× POWER 1× Internet 1× LAN 3× Signal |
| Retail Package Dimension | 303 × 288 × 65 |
| Units per Carton | 10 |
| Carton Dimension | 590 × 315 × 340 |
- Others
| Certifications | CE |
|---|---|
| Network Services Enabled by Default |
Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP DHCP Server IP address assignment (DHCP) • Port: 67 Protocol: UDP App management Manage and configure device through app • Port: 20001 Protocol: TCP • Port: 20002 Protocol: UDP |
| Package Contents | AC1200 Wireless Dual Band 4G LTE Router (MB135-4G) Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| Environment | Operating Temperature: 0 °C~40 °C (32 °F~104 °F) Storage Temperature: -40 °C~60 °C (-40 °F~140 °F) Operating Humidity: 10%~90% Non-Condensing Storage Humidity: 5%~90% Non-Condensing |
